WARNING : Warning devices are strictly
regulated and governed by Federal, State and
Municipal ordinances. These devices shall be
used ONLY on approved vehicles. It is the sole
responsibility of the user of these devices to
ensure compliance.
EL3D08A(xxx) 3.09
! WARNING
This product contains high intensity LED devices.
To prevent eye damage, DO NOT stare into light
beam at close range.
PATTERN SELECTION
1. Connect BLACK wire to ground.
2. Connect RED wire to +Vdc.
3. Connect GREEN and BLUE wires to +Vdc.
4. With power applied to the two wires
momentarily apply power to WHITE wire to
change the directional arrow patterns.
5. While changing patterns, the UltraLITE will
display the left arrow pattern.
6. When you have chosen the directional arrow
pattern, disconnect GREEN and BLUE wires
from power.
7. Connect BROWN wire to +Vdc and
momentarily apply +Vdc to WHITE wire to
change the warning pattern displayed on the
UltraLITE.
8. When you have selected the warning pattern
for the UltraLITE, disconnect BROWN wire
from power.
9. You are finished configuring the UltraLITE.
ARROW PATTERNS for
1 Solid Fast High Power
2 Solid Plus Fast High Power
3 Sequential Fast High Power
4 Sequential2 (2 lights) Fast High Power
5 Solid Slow High Power
6 Solid Plus Slow High Power
7 Sequential Slow High Power
8 Sequential2 (2 lights) Slow High Power
9 Solid Fast Low Power
10 Solid Plus Fast Low Power
11 Sequential Fast Low Power
12 Sequential2 (2 lights) Fast Low Power
13 Solid Slow Low Power
14 Solid Plus Slow Low Power
15 Sequential Slow Low Power
16 Sequential2 (2 lights) Slow Low Power
SINGLE END MODULE WARNING PATTERNS
1 Traffic Mover Simultaneous
2 Q-Switch Alternating
3 RoadRunner Alternating
4 Power Pulse Alternating
5 Progressive Alternating
Simultaneous: 1 and 8 together
Alternating: 1 alternates with 8
8 MODULE EXTERIOR BAR
DIRECTIONAL ARROW W/ WARNING TIPS
CONFIGURATION INSTRUCTIONS
12v: EL3DØ8A1Ø(x)
10-30v: EL3DØ8A1Ø(x)-24
10-30v w/ 50’ CABLE: EL3DØ8A(x)L(x)-24
