PMB3BKT Replacement Permanent Mount Bracket (each)
PMB3BRKT Replacement Permanent Mount Bracket (kit)
PMB3HBKT Replacement Permanent Mount Bracket - High Mount (each)
PMB3HBRKT Replacement Permanent Mount Bracket (kit) - High Mount
PMB3TD(x) EPL7000 Replacement Domes
Replacement Parts & Accessories:
TECHNICAL SPECIFICATIONS
Overall Dimensions: 14.25”L x 8.27”W x 2.93”H
Flash Patterns: 28 flash patterns
Input Voltage Range: 10 - 16 Vdc
Current Consumption: 2 Amps (Avg) - 4 Amps (Max)
# of LEDs: 24 Generation 3 LEDs
Operating Temperature: -40º to +65º C
Flash Patterns
Alternating Patterns
FPM
(Flashes per Minute)
1. Warp Alternating
2. Quad “
3. Quad2 “
4. Quint “
5. Double2 “
6. Warp 1, 2, 3 “
7. Progressive “
8. Q-Switch™ “
9. Intercycle “
10. Warp Whole Bar
11. Quad “
12. Quad2 “
13. Quint “
14. Double2 “
15. Warp 1, 2, 3 “
16. Progressive “
17. Warp Diagonal
18. Quad “
19. Quad2 “
20. Quint “
21. Double2 “
22. Warp 1, 2, 3 “
23. Progressive “
24. Q-Switch “
25. Intercycle “
26. Rotator “
27. Cycle 1 Random
28. Cycle 2 “
EPL71PD(xx) 11.14
EPL7100 MINI LIGHTBAR
PERMANENT MOUNT
EPL7PD(xx) Low Bracket (shown)
