8-Pin Mini-style Cordsets
The following cordsets have an 8-pin mini-style connection on one end and are made of 20 gauge wire.
Models Length Banner Cable Pinout/
Color Code
SAE H1738-22 Pinout/Color Code Pinout
Pin Color Pin Color
QDS-815C 4.51 m (15 ft) 1
2
3
4
5
6
7
8
Bn
Or/Bk
Or
Wh
Bk
Bu
Gn/Ye
Vi
1
2
3
4
5
6
7
8
Or
Bu
Wh/Bk
Bk
Wh
Rd
Gn
Rd/Bk
1
2
3
8
7
6
5
4
QDS-825C 7.62 m (25 ft)
QDS-850C 15.2 m (50 ft)
QDS-875C 22.9 m (75 ft)
Unterminated bulk cable is available (UTB-3...C, UTB-5...C, UTB-8...C) in 25 ft, 50 ft, 100 ft, and 250 ft lengths. For more
information, refer to www.bannerengineering.com .
STB Self-Checking Touch Button Replacement Parts
Model Description Product
STBVP6-78574
• Solid-state complementary PNP outputs
• Polyetherimide upper housing
• 300 mm (12 inches), 4-wire PVC-jacketed cable
E-Stop Push-Button Components Replacement Parts
SSA-EBM-02L
Metal E-stop button with 2 normally closed
(N.C.) contacts
8-LP2T-B6644
• 22.5 mm plastic button (mounting
adapter sold separately)
• Twist to release, mechanical latching
ISO 13850 (EN 418) compliant
• Diameter 40 mm (without mounting
adapter)
2 The SAE H1738-2 pin assignment and color codes are listed as a customer courtesy. The user must verify suitability of these
cables for each application.
