Model Description
STBA-RB2-MB3 • Swivel-mount bracket; mounts to telescoping stands below
• Holes for radial adjustment, 0°–30° in 10° increments
• Made of 12 ga cold-rolled steel with black powdercoat paint
• Replacement part; included with telescoping stands STBA-
RB2-S1 and STBA-RB2-S2
Telescoping Stands
Model Description
STBA-RB1-S1 • Floor-mounted, telescoping stand; locates touch buttons 800
to 1232 mm (31.5" to 48.5") above the floor surface
• 150 mm (5.9") square stationary floor base with 4 mounting
holes in corners
• Telescoping square tubes made of 12 ga cold-rolled steel;
base 1/4" cold-rolled steel; black powdercoat paint
• STBA-RB1-S1 includes swivel-mount bracket STBA-RB1-MB3
to mount STBVP6-RB1... Run Bars •
• STBA-RB2-S1 includes swivel-mount bracket STBA-RB2-MB3
to mount STBVP6-RB2... Run Bars
• See datasheet 135635 for more information on STBA-RB1-S1
• See datasheet 145295 for more information on STBA-RB2-S1
STBA-RB2-S1
DUO-TOUCH Run Bar with STB Buttons
Datasheet 131634_web Rev.
