PC-2200
BOWERS METROLOGY page 30 /32 version 2.06 -E
6.4 BLANK SETTING SHEET
Menu Sub-menu Selection Function Choice Values
CHANNEL SOURCE EXT.
CH-BUS
CH-A RATIO 0 - 5.000
DIREC. + / -
CH-B RATIO 0 - 5.000
DIREC. + / -
CH-C RATIO 0 - 5.000
DIREC. + / -
CH-D RATIO 0 - 5.000
DIREC. + / -
MEASURE M1 SELECT ON
BAR BOTTOM
CENTER
-10->0
B.FACT -5.00 / +5.00
RANGE ± 1.0mm
± 0.5mm
± 0.1mm
± 0.05mm
± 0.01mm
± 0.005mm
SENS. ± 0.01 ~ 5.000
RESOL. 0.01, 0.005, 0.001,
0.0005, 0.0002,
0.0001
FUNC A, B, C, D, A+B, A-B,
C+D, (A+B)-C,
(A+B+C)/3,
(A+B+C+D)/4
(A+B)-(C+D)
MODE STATIC, MAXIMUM,
MINIMUM,(M+m)/2,
(M-m)/2, M-m
SPEC. M1 NOMI. 000.0000
-TOLER. -0.8000
+TOLER +0.0000
-APPRO -0.0000
+APPRO +0.0000
MASTER M1 -MASTER +00.0000
+MASTER +00.0000
CLASS SELECT OFF / ON
NUMBER 1 - 100
START +00.0000
STEP 0.0000
RS232 SPEED 19200, 9600, 4800
DATA 7, 8
PARITY None,even,Odd
TERM CR,CRLF
RTS ON / OFF
PRINT BRIEF, FULL
RSMODE PRINT,HOST
ID NO. 000
ETC GENERAL UNIT METRIC,INCH
DISPLAY mm, um
INPUT HBT,LVDT,CAP,AIR
P/W PROGRAM
CALIBR. ON/OFF
AVERAGE BAR 000
DIGIT 000
A/D 00
VERSION
Nominal size :
Lower tolerance:
Upper tolerance:
Lower warning limit:
Upper warning limit:
Lower master :
Upper master:
Unit : mm
