Pc-2200 – Bowers Group Advanced Electronic/Air Column PC-2200 User Manual
Page 22

PC-2200
BOWERS METROLOGY page 22 /32 version 2.06 -E
Menu Sub-menu
Functions
Functions Functions
CLASS
Select
ON/OFF
NUMBER
START
STEP
000
+0.0000”
0.0000
CLASS : Switch ON or OFF the class menu.
NUMBER : Store the number of classes to be used.
START : Store the starting nominal value
STEP
: Store the step value of the class.
Menu Sub-menu
Functions
Functions Functions
RS232
SPEED
DATA
PARITY
TERM
RTS
PRINT
RSMODE
ID NO.
4800,9600,19200 BAUD RATE
7,8 Bits
NONE, ODD,EVEN
CRLF / CR
ON / OFF
BRIEF / FULL
PRINT /HOST
000
SPEED : Select the transmission speed .
DATA
: Select the word length.
PARITY : Select the parity control : none, even, odd
TERM
: Select the end characters : CR, CRLF
RTS
: (Request to Send) request to send a signal
: Select the printing mode, (BRIEF) send the minimum data, (FULL) send a complete protocol.
RS232
: Select the RS232 Interface in mode PRINT(Simplex) or HOST (Duplex)
ID NO
: Store an identity number.
Menu Sub-menu
Functions
Functions
Functions
ETC
GENERAL
AVERAGE
VERSION
UNIT
DISPLAY
INPUT
P/W
BAR
DIGIT
A/D
PROGRAM
CALIBR.
METRIC, INCH
mm or um
HBT,LVDT,CAP_1,CAP_5,AIR
0000
ON/OFF 0000
005
005
20
v 2.xx BMI
GENERAL : Select the measuring unit, select the display (mm or um), select the analog board used, store a
PROGRAM password and a CALIBRATION password.
AVERAGE : BAR, Store a filter for the bar.
DIGIT, Store a filter for the digital display.
A/D, Store a filter for analog/digital converter.
VERSION : Show the software version.
※
When changing the unit(metric to inch or inch to metric) it will be automatically out of the program without
saving or confirming. The user should check the specification input after going into the program again.
