7 - 8 ROUTINE MAINTENANCE AND CONSUMABLE REPLACEMENT
6
Remove the polystyrene packing and open the top
of the aluminum package from the left and right.
7
Take the new print head cartridge out of its package
and pull each of the 4 seals one at a time to remove
them. Pull the seals straight out.
■ Keep the print head cartridge polystyrene
packing, aluminum package, and box in case
you need to transport the printer over long
distances in the future.
■ If there is no circle on the end of the seal, you
can not use this print head cartridge. Contact
your dealer or Brother Customer Service for
assistance.
8
Remove the tape from the top of the cartridge (1),
hold the protective cover on both sides and remove
it from the print head cartridge (2).
9
Grip the handle on top of the print head cartridge
and face the flat part towards the back of the printer.
1. Flat part facing to the back
