Appendix A Equipment Phase Instructions (PSC, PCMD, POVR, PFL, PCLF, PXRQ, PRNP, PPD, PATT, PDET)
PXRQ Error Codes
Arithmetic Status Flags: not affected
Fault Conditions: none
ERR (hex) EXERR (hex) Description Recommended Action
00 0000 The PXRQ instruction was aborted before it
sent the request to FactoryTalk Batch
software. None
01 0000 The PXRQ instruction was aborted after it
sent the request to FactoryTalk Batch
software. None
02 0000 2 or more PXRQ instructions executed at the
same time using the same request type Limit execution to 1 PXRQ instruction at a time.
03 0110 Communication error. The request was not
delivered because there is no subscriber
subscribed to the phase. Check that FactoryTalk Batch software is connected and
running.
0210 Communication error. The request was not
delivered because there is no connection to
the Notify object. Check that FactoryTalk Batch software is connected and
running.
0410 Communication error. Delivery failed. Check the connection and communication path to
FactoryTalk Batch software.
1010 Communication error. The request was not
delivered because FactoryTalk Batch
software does not subscribe to receive the
external request. Check that FactoryTalk Batch software is connected and
running.
1020 FactoryTalk Batch software isn’t attached to
the phase. Check that FactoryTalk Batch software is attached to the
phase.
04 0002 The FactoryTalk Batch software
encountered an error while processing the
request. Check the connection and communication path to
FactoryTalk Batch software.
0003 The PXRQ instruction contains an invalid
value. Check the connection and communication path to
FactoryTalk Batch software.
0004 FactoryTalk Batch software is not in the
proper state to process the request. Check the connection and communication path to
FactoryTalk Batch software.
0005 2 or more PXRQ instructions executed at the
same time using different request types Limit execution to 1 PXRQ instruction at a time.
0006 Error storing to parameter tags at end of
request processing. Check the connection and communication path to
FactoryTalk Batch software.
05 0000 FactoryTalk Batch software received the
request but passed back an invalid cookie. Check the connection and communication path to
FactoryTalk Batch software.
06 0000 PXRQ instruction sent an invalid parameter
to FactoryTalk Batch software. Check the connection and communication path to
FactoryTalk Batch software.
07 0000 Communication lost while PXRQ is waiting
for response from FactoryTalk Batch
software. Check the connection and communication path to
FactoryTalk Batch software.
