Publication LOGIX-UM001B-EN-P - April 2010 29
Guidelines Chapter 3
Done
RUNNING
· Lock equipment in
program control
· Add water
· Unlock equipment
from program
control
HOLDING
· Stop water
· Unlock equipment
from program
control
RESTARTING
· Lock equipment in
program control
HELD
· No water flow
· Operator can
control equipment To
Hold
Command
Restart
Command
Stop
Command
Done
STOPPING
· Stop water
· Unlock equipment
from program
control
STOPPED
· No water flow
· Operator can
control equipment
RESETTING
IDLE
· No water flow
· Tank Not full
· Operator can
control equipment
ABORTED
· No water flow
· Operator can
control equipment
ABORTING
· Stop water
· Unlock equipment
from program
control
Start
Command
COMPLETE
· No water flow
· Water at high limit
· Operator can
control equipment
Waiting State Acting State
Key
Done
Reset
Command
Done
Done
Hold
Command
Done
Reset
Command
Abort
Command
Abort
Command
Equipment Phase: Add Water Example 1: Add Water
