PHASE Data Type Appendix B
see if the equipment phase is in the stopped
state Stopped BOOL Read–only
see if the equipment phase is in the aborted
state Aborted BOOL Read–only
use one member to monitor the substate of an
equipment phase Substate DINT Read–only
For this substate Use this bit
Pausing 0
Paused 1
AutoPause 2
see if the equipment phase is in the pausing
substate Pausing BOOL Read–only
see if the equipment phase is in the paused
substate Paused BOOL Read–only
see if the equipment phase is in the
auto pause substate AutoPause BOOL Read–only
use an integer value or the bits of an integer to
sequence through a series of steps StepIndex DINT • To initialize the StepIndex value, use the
configuration properties for the
equipment phase.
• To advance to the next step, use logic
such as an MOV, MUL, or := to increment
the StepIndex value.
flag a specific exception for an equipment
phase (fault, failure, off-normal condition, and
so forth.) Failure DINT To Use
set a Failure value PFL instruction
clear the Failure value PCLF instruction
find the unit ID of an equipment phase UnitID DINT FactoryTalk Batch software sets this value.
monitor the ownership of an equipment phase Owner DINT Read–only
see if an external request is in process via a
PXRQ instruction PendingRequest DINT • Read–only
• Each bit = the state of a specific request,
starting with bit 0. The bits are in the
order shown by the request-specific
members below.
see if a Download Input Parameters request is
in process via a PXRQ instruction DownloadInputParameters BOOL Read–only
see if a Download Input Parameters Subset
request is in process via a PXRQ instruction DownloadInputParameters
Subset BOOL Read–only
see if a Upload Output Parameters request is
in process via a PXRQ instruction UploadOutputParameters BOOL Read–only
see if a Upload Output Parameters Subset
request is in process via a PXRQ instruction UploadOutputParameters
Subset BOOL Read–only
see if a Download Output Parameter Limits
request is in process via a PXRQ instruction DownloadOutput
ParameterLimits BOOL Read–only
see if an Acquire Resources request is in
process via a PXRQ instruction AcquireResources BOOL Read–only
If you want to Then check this
member Data type Notes
