Rockwell Automation Publication LDC-UM001B-EN-P - March 2011 69
Specifications and Dimensions Appendix A
Table 16 - Weight Specifications - Motor Magnet Track
Carriage Weight and Heat Sink Area Requirements
Cat. No.
Magnet Track Weight, approx.
kg (lb)
LDC-M030100 0.47 (1.02)
LDC-M050100 0.66 (1.46)
LDC-M075100 0.90 (1.98)
LDC-M100100 1.14 (2.51)
LDC-M150100 1.62 (3.57)
LDC-M030500 2.35 (5.12)
LDC-M050500 3.32 (7.28)
LDC-M075500 4.5 (9.92)
LDC-M100500 5.7 (12.57)
LDC-M150500 8.08 (17.81)
Cat. No. Required Heat Sink Area
cm
2 (in. 2 )
Required Carriage Plate
Weight, approx.
kg (lb)
LDC-C030100-DHTxx 150 X 200 (6 X 8) 1.1 (2.6)
LDC-C030200-xHTxx 150 X 300 (6 X 12) 1.6 (3.6)
LDC-C050100-DHTxx 200 X 200 (8 X 8) 1.8 (4)
LDC-C050200-xHTxx 200 X 300 (8 X 12) 2.7 (6)
LDC-C050300-xHTxx 200 X 400 (8 X 16) 3.6 (8)
LDC-C075200-xHTxx 250 X 300 (10 X 12) 5.4 (12)
LDC-C075300-xHTxx 250 X 400 (10 X 16) 7.3 (16)
LDC-C075400-xHTxx 250 X 500 (10 X 20) 9.1 (20)
LDC-C100300-xHTxx 300 X 400 (12 X 16) 8.7 (19.2)
LDC-C100400-xHTxx 300 X 500 (12 X 20) 10.9 (24)
LDC-C100600-xHTxx 300 X 750 (12 X 30) 19.6 (43.2)
LDC-C150400-xHTxx 400 X 500 (16 X 20) 21.8 (48)
LDC-C150600-xHTxx 400 X 750 (16 X 30) 32.7 (72)
