80 Publication 2711-QS003D-EN-P - June 2009
Appendix A Application Programs
PanelBuilder32 Application
Programs PanelBuilder32 application files are on the PanelBuilder32 installation
CD in the QuickStart\PV directory.
PanelBuilder32 Application Files (\Quickstart\PV directory)
File Name Use with this application
CL_DHP.pba
•
ControlLogix controller with DH+ module (1756-DHRIO)
•
DHRIO module configured for slot 1
•
Channel 1 of DHRIO set for 57.6K baud
CL_rio.pba
•
ControlLogix controller with RIO Module (1756-DHRIO)
•
DHRIO module in slot 1
•
Channel 2 of DHRIO set for 57.6K baud
CLCNetS.pba
•
ControlLogix with a ControlNet Bridge (1756-CNB)
•
ControlNet Bridge configured for slot 1
•
Scheduled messaging
CLCNetU.pba
•
ControlLogix with a ControlNet Bridge (1756-CNB)
•
ControlNet Bridge configured for slot 1
•
Unscheduled messaging
CL_Enet.pba
•
ControlLogix controller with 1756-ENET/B module
•
Network addressing
•
Slot 1
PLC_Enet.pba
•
PLC-5E (Ethernet) controller
SLC_Enet.pba
•
SLC 5/05 (Ethernet) controller
DF1.pba
•
Any enhanced PLC-5, SLC-5/03, 5/04, 5/05, Micrologix
controller
DNet.pba
•
1756-DNB configured for slot 1 with ControlLogix controller or
•
1771-SDN configured for slot 1with PLC-5 controller or
•
1747-SDN configured for slot 1 with SLC controller
MLDH485.pba
•
MicroLogix controller with RS-485
PLC_DHP.pba
•
PLC-5 controller with Data Highway +
PLC_RIO.pba
•
PLC-5 controller with Remote I/O
PLCCNetU.pba
•
PLC-5 controller with ControlNet
•
Unscheduled messaging
SLC_DHP.pba
•
SLC 5/04 with Data Highway +
SLC_RIO.pba
•
SLC with Remote I/O
•
Remote I/O module configured for slot 1
SLCDH485.pba
•
1761-NET-AIC may be required
•
Any SLC controller
SLC 5/04 or 5/05 channel 0 can be configured for DH485
protocol.
•
Configure the PanelBuilder application to match the PanelView
catalog number.
