Alarm banner – Rockwell Automation 2711-ND3 PanelBuilder32 Quick Start Manual User Manual
Page 77

Publication 2711-QS003D-EN-P - June 2009
77
Running the Application Chapter 7
2. Enter a motor speed between 600 and 1800 on the scratchpad
using the numeric entry keys.
On touch screens, touch the numeric keys displayed on the
screen.
3. Press Enter (
↵ )
to save the value and close the scratchpad.
4. Press the [F2] key. On touch screens, touch
Notice the new motor speed displayed on the Status screen.
The new speed will not take effect until the motor is stopped and
restarted.
Alarm Banner
Create an alarm condition by entering a motor max speed between
1200 and 1500 as described in the previous section and then starting
the motor. An alarm banner is displayed over the current screen.
To acknowledge the alarm, press the [F4] key. On touch screens,
touch
The alarm banner is cleared.
TIP
During data entry, wait until the number you enter
appears in the scratchpad before entering the next
number.
Motor
Status
F2
Motor
Speed
F3
Stop
Motor
F2
Start
Motor
F1
Motor Stopped
Speed
8
MOTOR SPEED HIGH
Ack
F4
TIP
When the motor speed is in the range 1500 -1800 rpm, a
different alarm message is displayed.
Ack
F4
