Page 75: Running the application, Chapter
75
Publication 2711-QS003D-EN-P - June 2009
75
Chapter
7
Running the Application
This chapter provides some guidance in checking the operation of the
application.
Motor Status Screen
After receiving the downloaded application, the PanelView terminal
displays the Motor Status screen
Follow these steps to start and stop the motor:
1. Press the [F1] key. On touch screens, touch
Notice how the Start / Stop Motor push button changes each
time it is pressed.
2. Stop the motor by pressing [F2] or on touch screens
Notice that the stop button also changes inner text each time it is
pressed.
3. Press the Motor Start/Stop buttons and note how the motor
status indicator also changes.
Motor
Speed
F3
Stop
Motor
F2
Start
Motor
F1
MOTOR STATUS SCREEN
Motor Stopped
Motor Speed
568
Start
Motor
F1
Start
Motor
F1
Motor
Started
Stop
Motor
F2
Stop
Motor
F2
Motor
Stopped
