64
Publication 2711-QS003D-EN-P - June 2009
Chapter 5 Entering Application Tags
Description of the
Application Tags
DH-485, DH+, and DF1 Application Tags
The table shows application tags used by the DH-485, DH+, and DF1
applications. Defaults are accepted for fields not shown in table.
These tags are also used for EtherNet/IP (to a PLC-5E or SLC) and
ControlNet (to a PLC-5C).
Remote I/O Application Tags
The table shows application tags used by the Remote I/O application.
Defaults are accepted for fields not shown in table.
Tag Name
Data Type
Tag
Address
Description
Node
Name
Initial
Value
Min
Max
Start_Motor
Bit
B3:0/0
Starts the motor
LC_1
0
0
0
Stop_Motor
Bit
B3:0/1
Stops the motor
LC_1
0
0
0
Motor_Status_Ind
Bit
B3:0/2
Shows on/off motor status
LC_1
0
0
0
Motor_Speed
Unsigned
Integer
N7:0
Shows the motor speed
LC_1
0
0
65535
Set_Max_Motor_Speed
Unsigned
Integer
N7:1
Sets the maximum speed
LC_1
1800
600
1800
Speed_Alarm
Bit
B3:1/0
Triggers alarm messages
LC_1
0
0
0
Tag Name
Data Type
Tag
Address
Description
Node
Name
Initial
Value
Min
Max
Start_Motor
Bit
I
:010/0
Starts the motor
LC_1
0
0
0
Stop_Motor
Bit
I
:010/1
Stops the motor
LC_1
0
0
0
Motor_Status_Ind
Bit
O:010/0
Shows on/off motor status
LC_1
0
0
0
Motor_Speed
Unsigned
Integer
O:011
Shows the motor speed
LC_1
0
0
65535
Set_Max_Motor_Speed
Unsigned
Integer
I
:011
Sets the maximum speed
LC_1
1800
600
1800
Speed_Alarm
Bit
O:012/0
Triggers alarm messages
LC_1
0
0
0
