5–35 Configuring Your Reader
Publication 2755-6.9
•
I 2 of 5. Code length #1 can be zero or any even number from 2
to 64. The default is 10. Code length #2 can be zero or any even
number from 2 to 64. The default is 6.
Command Parameter Format Example
Status
0 = Disabled
1 = Enabled
Check Digit Status
To set Fixed Code Length #1 to 8 and #2
0 = Disabled Kr
digit output,length 1, To set Fixed Code Length #1 to 8 and #2
to 4, press
[] or
1 = Enabled
Kr digit output,length 1,
length 2> to 4, press [] or
[] .
Check Digit Output Status
0 = Disabled
1 = Enabled
•
UPC/EAN. The Separator character can be any ASCII character
except NUL. The default is , .
Command Parameter Format Example
UPC Status
0 = Disabled
1 = Enabled
EAN Status (UPC must be enabled)
0 = Disabled
1 = Enabled
status,supplementals
To change Supplementals to Required,
Supplementals Status Ks
status,supplementals
status,separator
and change Separator Character to a
0 = Disabled
Ks status,separator
status,separator cha.>
dash (–), press
[]
1 = Enabled
[] .
2 = Required
Separator Status
0 = Disabled
1 = Enabled
•
Code 128. You can use any number between 1 and 64 for the
Code Length. The default is 10.
Command Parameter Format Example
Status
0 = Disabled
1 = Enabled
To enable Code 128, enable Fixed Code
Fixed Code Length Status
Kt Length, and set Code Length to 9, press
[]
0 = Disabled
length,length> [] .
1 = Enabled
•
Code Types Status Request. Allows you to return the status of
each command in the group.
Parameter Format
KW
