5–28
Configuring Your Reader
Publication 2755-6.9
Communications Commands
•
Protocol. If selecting one of the options from 0 to 4
(Point-to-Point, Point-to-Point with RTS/CTS, Point-to-Point
with XON/XOFF, Point-to-Point with RTS/CTS and
XON/XOFF, or Polling Mode D), use the format below.
Command
Parameter
Format
Example
Protocol
0 = Point-to-Point
1 = Point-to-Point with RTS/CTS
To change the Protocol to Polling Mode
2 = Point-to-Point with XON/XOFF
Kf
To change the Protocol to Polling Mode
D, press
[
.
3 = Point-to-Point with RTS/CTS and XON/XOFF
[
]
4 = Polling Mode D
If selecting Multidrop (5), you must define an address and append
it to the command string. The address can be from 1 to 50.
Command
Parameter
Format
Example
Protocol
To change the Protocol to Multidrop with
5 = Multidrop
Kf
an address of 33, press
[
.
If selecting User Defined (6) or User Defined Multidrop (7),
complete the format by either choosing new parameters or
concatenating unchanged data fields (separate by commas).
For User Defined, first select Point-to-Point
Defined
Multidrop
Command
Parameter
Format
Example
Protocol
To select an unpolled ACK/NAK User
6 = User Defined
Kf
Defined protocol with LRC disabled,
press
[
^F ^U
K 0 ]
➀
7= User Defined Multidrop
NAK>
^F,^U>
➀
. ACK and NAK
will be displayed in the menu
➁
.
➀
➁
A control character, represented here as two characters (^F or ^U, etc.), is actually a single ASCII
character that is entered on the keyboard by holding down the control key while pressing the
desired letter.
•
Preamble. You can enter one or two preamble characters except a
null (00H).
Command
Parameter
Format
Example
Status
To enable Preamble with just one
0 = Disabled
Kd
To enable Preamble with just one 1 = Enabled Kd character(s)> character, an FF (form feed), press [ .
character, an FF (form feed), press
