Publication 2090-IN009F-EN-P — November 2004
Resistive Brake Module Installation Instructions 7
Figure 4
2090-XB120-xx Mounting Dimensions
Figure 5
2090-XB120-xx Minimum Clearance Requirements
195.0
(7.68)
7.8
(0.31)
305.6
(12.03)
10.4
(0.41)
190.3
(7.49)
110.9
(4.37)
328.17
(12.92)
339.8
(13.38)
4.57
(0.18)
55.6
(2.19)
25.66
(1.01)
18.05
(0.71)
16.0
(0.63)
Dimensions are in millimeters (inches).
Clearance right
of RBM is not
required Clearance left
of RBM is not
required
50 mm (1.97 in.)
clearance for airflow
50 mm (1.97 in.)
clearance for airflow
