22 Resistive Brake Module Installation Instructions
Safety Contactor Specifications - Allen-Bradley 100S Series
The information in this section is adapted from the Allen-Bradley Safety Product
Catalog (Publication S114-CA001x-EN-P). That document should be referred
to for the most recent information on the 100S Series Contactors.
Clearances
2
• Top
• Side
• Bottom 50 mm
0 mm
50 mm (1.97 in.)
(0 in.)
(1.97 in.)
Weight
• 2090-XB33-16
• 2090-XB33-32
1.91 Kg (4.22 lbs)
• 2090-XB120-01
• 2090-XB120-03
• 2090-XB120-06
2.75 Kg (6.06 lbs)
1 Additional dimensional information is provided in Figure 2 on page 6.
2 Combustible material adjacent to the brake module may require additional restrictions
(i.e., Clearance based on ambient temperature of the brake module within the application).
Mechanical Specifications Value
24V Coil Power
Specifications Voltage Range
Vdc Coil Consumption
Watts Operating Time
milliseconds
Pickup 19.2 to 26.4 9.2 40 to 70
Dropout 2.4 to 14.6 0 17 to 23
Hold-In 14.6 to 26.4 9.2 N/A
I
e
Ratings for Switching AC Motors - AC-2, AC-3, AC-4
[A] kW (50 Hz) HP (60 Hz)
AC-3 AC-1 230V 380V, 415V, 400V 500V 690V
1
∅
3
∅
115V 230V 200V 230V 460V 575V
23 32 7.5 11 11 11 2 3 5 7.5 15 15
230V Coil Power
Specifications Voltage Range
Vac Coil Consumption
VA/W Operating Time
milliseconds
Pickup 195.5 to 253.0 200/110 20.0 to 40.0
Dropout 69.0 to 138.0 0 10.0 to 60.0
Hold-In 138.0 to 253.0 16/4.5 N/A
I
e
Ratings for Switching AC Motors - AC-2, AC-3, AC-4
[A] kW (50 Hz) HP (60 Hz)
AC-3 AC-1 230V 380V, 415V, 400V 500V 690V
1
∅
3
∅
115V 230V 200V 230V 460V 575V
85 100 25 45 45 45 7.5 15 25 30 60 60
