Publication 2090-IN009F-EN-P — November 2004

20

Resistive Brake Module Installation Instructions

Environmental Specifications

Value

Vibration
• operating

0.35 mm (0.014 in.) max.
displacement at 5-53 Hz
2g max. acceleration at

53 to 500 Hz

Shock
• operating

15g, 11 msec half sine

Altitude

1500 m

(5000 ft)

Humidity

5% to 95% non-condensing

Storage temperature

-25° C
70° C

(-13° F)
(158° F)

Ambient operating temperature

1

• minimum
• maximum

0° C
50° C

(32° F)
(122° F)

Air flow clearance
• above and below
• left and right

50 mm
0 mm

(1.97 in.)
(0 in.)

Temperature limits
• T1 (Fault)
• T2 (Warning output)

80°±5° C
65°± 5° C

(176±9° F)
(119°±9 ° F)

Duty cycle:
• 2090-XB33-16
• 2090-XB33-32
• 2090-XB120-01
• 2090-XB120-03
• 2090-XB120-06

Complete stop with

2

15:1 inertia mismatch

60 per hour, or

2

once per minute

1Power performance increases about 5.5W for every 1°C (3.1W/°F) drop in ambient temperature.

2 Refer to the Motion Control Selection Guide (publication GMC-SG001x-EN-P) for proper sizing.

Connectors

Type

Torque
Nm

(lbs-in.)

2090-XB33-xx

Drive Connection (TB1)

4-position plugable
Phoenix-type

(7.62mm spacing)

0.5 - 0.6

(4.4 - 5.3)

Motor Connection (TB2)

0.5 - 0.6

(4.4 - 5.3)

I/O Terminals (TB3)

1

8-position plugable
Phoenix-type

(5.08mm spacing)

0.22 - 0.25

(1.9 - 2.2)

2090-XB120-xx

Drive Connection (TB1)

4-position plugable

42 Series Molex

(12mm spacing)

2.5 - 2.9

(22.1 - 25.7)

Motor Connection (TB2)

2.5 - 2.9

(22.1 - 25.7)

I/O Terminals (TB3)

8-position plugable
Phoenix-type

(5.08mm spacing)

0.22 - 0.25

(1.9 - 2.2)

230V Power Terminals (TB4)

2-position plugable
Phoenix-type

(7.62mm spacing)

0.5 - 0.6

(4.4 - 5.3)
