Power Dissipation
Specifications
Use the following table to size an enclosure and calculate required
ventilation for your 8720MC system.
1
The open packaged drive ambient operating temperature is 50°C (122° F). The cabinet enclosure should be
designed to provide an operating temperature that does not exceed 50°C (122° F) in worst case ambient
conditions.
2
Drive rating is based on altitudes of 1000 meters (3000 feet) or less. If installed at a higher altitude, derate the
drive.
External Active Shunt
Specifications
The table below lists the ratings for the (optional) external active
shunt module (for use with the 8720MC-B021, -B027, -B034, -B042,
and -B048).
Catalog
Number
8720MC-
Base Derate
Amps
2
Drive Frame
Size
Heat
Dissipation
(Drive) Watts
1,2
Heat sink
Watts
1,2
Total Watts
1,2
380 - 480V ac or 750V dc Input Drives
B014
14
B
91
270
361
B021
21
B
103
394
497
B027
27
B
117
486
603
B034
34
B
140
628
768
B042
42
B
141
720
861
B048
48
B
141
820
961
D065
65
C
175
933
1108
D078
78
C
193
1110
1303
D097
97
D
361
1708
2069
D120
120
D
361
1708
2069
D149
149
D
426
1944
2307
D180
180
D
522
2664
3186
External Shunt
Catalog Number
Drive
Voltage
V ac
Ratings
Shipping
Weight
kg (lbs)
Bussmann
Replacement Fuse
Resistance
Range
Ohms
Peak
Power
kW
Peak
Current
Amps
Cont.
Power
Watts
1336-MOD-KB005
460
104.0
6
7.5
375
6.8 (15)
A60Q
1336-MOD-KB010
460
52.0
12
15
750
A60Q
1336-MOD-KB050
460
10.0
60
76
3750
33.8 (75)
A70QS35
