Chapter 1 - installing your 8720mc drive, Chapter objectives, Chapter 1 – Rockwell Automation 8720MC High Performance Drives Installation Manual User Manual
Page 13: Installing your 8720mc drive, Chapter objectives -1
1
Publication 8720MC-IN001D-EN-P — December 2002
Chapter
1
Installing Your 8720MC Drive
Chapter Objectives
This chapter provides system installation guidelines and procedures
for mounting your 8720MC drive. This chapter covers the following
topics:
• Complying with European Union Directives
• 8720MC Drive Component Overview
• Before Mounting Your System
• HF Bonding Your System
• Planning Your Panel Layout
• Mounting Your 8720MC Drive System
Note: Refer to the 8720MC Regenerative Power Supply User Manual
(publication 8720MC-UM001x-US-P) for 8720MC-RPS installation
instructions.
ATTENTION
!
The following information is a guideline for proper
installation. The National Electrical Code and any
other governing regional or local codes overrule this
information. The Allen-Bradley Company cannot
assume responsibility for the compliance or the
noncompliance with any code, national, local or
otherwise, for the proper installation of this system
or associated equipment. If you ignore codes during
installation, hazard of personal injury and/or
equipment damage exists.
