Installing Your 8720MC Drive 1-3
Low Voltage Directive
These units are tested to meet Council Directive 73/23/EEC Low
Voltage Directive. The EN 60204-1 Safety of Machinery-Electrical
Equipment of Machines, Part 1-Specification for General Requirements
standard applies in whole or in part. Additionally, the standard
EN 50178 Electronic Equipment for use in Power Installations applies
in whole or in part.
8720MC Drive Component
Overview This section provides an overview of the 8720MC drive components
and a typical installation.
Note: Refer to Appendix C for a complete list of catalog numbers for
the 8720MC components listed above.
8720MC
Component:
Catalog Numbers: Description:
8720MC Drives
8720MC-Bxxx-Ax-HASx The 8720MC drives available with 14, 21, 27, 34, 42, and 48A (max.) continuous output current.
8720MC-Dxxx-Ax-HASx The 8720MC drive available with 65, 78, 97, 120, 149, and 180A (max.) continuous output current.
8720MC
Regenerative Power
Supplies
8720MC-RPS-xxxBx-xxx
The 8720MC regenerative power supply available with 27, 64, and 190 (max.) motor amps. Included
with regenerative power supply is the 8720MC-HF-B2 harmonic filter and 8720MC-VA-B varistor.
8720MC Line
Reactors
8720MC-LR-xxxxx The 8720MC line reactors with 32, 48, 62, and 70A current ratings.
ControlLogix
Chassis with
SERCOS interface
module
1756-MxxSE
The 1756-MxxSE SERCOS interface module serves as a link between the ControlLogix platform and
8720MC system. The communication link uses the IEC 61491 SErial Real-time COmmunication
System (SERCOS) protocol over a fiber-optic cable.
RSLogix 5000™
software
9324-RLD300ENE
RSLogix 5000 provides support for programming, commissioning, and maintaining the Logix family
of controllers.
Motors
MPL-B8xxx, -B9xxx and
8720SM S1 and S2 These MP-Series (permanent magnet) and 8720SM (induction) motors are available for use with the
8720MC drives in SERCOS interface mode.
8720SM S3 and S4 These 8720SM (induction) motors are available for use with the 8720MC drives in analog mode.
Motor Power
Cables
2090-CDNPBMP-8Sxx
Quick release, straight connectors at the motor and flying leads at the drive end. For use with
MPL-B860x, -B880x, -B960x, -B980Bx, and -B980C motors.
2090-MCNPMP-6Sxx
Quick release, straight connectors at the motor and flying leads at the drive end. For use with
MPL-B980D motors.
Motor power cables for all 8720SM motors are customer supplied.
Feedback Cables
2090-CDNFDMP-Sxx
Quick release, straight connectors at the motor and flying leads at the drive end. For use with all
applicable MP-Series motors and 8720SM-xxxxxxxS1, -xxxxxxxS2, and -xxxxxxxS4.
Motor feedback cables for all 8720SM-xxxxxxxS3 motors are customer supplied.
SERCOS Fiber-Optic
Cables
2090-SCxxx-x
SERCOS fiber-optic cables are available in four types (inside enclosure, outside enclosure, outside
enclosure in harsh environments, and glass). All four types include connectors at both ends.
AC Line Filters
8720MC-RFI80
The 8720MC-RFI80 three-phase AC line filter is suitable for use with the 8720MC-RPS27 and
-RPS65 regenerative power supply.
8720MC-EF190-VB
The 8720MC-EF190-VB three-phase AC line filter is suitable for use with the 8720MC-RPS190
regenerative power supply.
External Active
Shunt Module
1336-MOD-KBxxx
The Bulletin 1336 Heavy Duty Dynamic Brake is available when the 8720MC-RPS is not part of the
configuration.
