1-22 Installing Your 8720MC Drive
Mounting Your 8720MC
Drive System The procedures in this section assume you have prepared your panel
and understand how to bond your system.
For installation instructions regarding equipment and accessories not
included here, refer to Related Documentation in the Preface for the
appropriate publication number.
To mount your 8720MC drive:
1. Layout the position for the 8720MC and accessories in the
enclosure. Refer to Establishing Noise Zones for panel layout
recommendations. Mounting hole dimensions for the 8720MC are
shown in Appendix A.
2. Attach the 8720MC to the cabinet, first using the upper mounting
slots of the drive and then the lower. The recommended mounting
hardware is M5 metric (1/4-20) or #10 MS bolts. Observe bonding
techniques as described in HF Bonding Your System.
3. Tighten all mounting fasteners.
ATTENTION
!
This drive contains ESD (Electrostatic Discharge)
sensitive parts and assemblies. You are required to
follow static control precautions when you install,
test, service, or repair this assembly. If you do not
follow ESD control procedures, components can be
damaged. If you are not familiar with static control
procedures, refer to Allen-Bradley publication
8000-4.5.2, Guarding Against Electrostatic Damage
or any other applicable ESD Protection Handbook.
IMPORTANT
To improve the bond between the 8720MC and
subpanel, construct your subpanel out of zinc
plated (paint-free) steel.
