5–15 Configuring Communications Settings for 1000e/1200e/1400e Application Transfers
Publication 2711E-6.8 – January 1998
For Ethernet, specify www.xxx.yyy.zzz, where www, xxx, yyy,
and zzz are between 000 and 255 (decimal); or specify one to
eight characters, where the first character must be alphabetic.
The bridge address format for DH+ is as follows:
Station Address Valid DH+ Entries
ll.rrr.ss
ll local bridge address
rrr remote bridge address
ss station address on remote DH+
0 – 77 (octal)
0 – 376 (octal)
0 – 77 (octal)
or
You can shorten the offlink address by combining the remote bridge and remote
station addresses into one three-digit number. The system reads only the first digit of
the remote bridge address, and adds the two-digit remote station address to produce a
shorter address that still points to the same node.
ll.rss
ll
local bridge address
rss combined remote bridge address and
remote station
address
0 – 77 (octal)
0 – 376 (octal)
ll
ll local bridge address 1 – 63 (decimal)
For bridge address configuration examples, refer to “Planning
DH+ or ControlNet Communications” in Chapter 2, “Planning
Applications,” of the PanelBuilder 1400e Configuration Software
for Windows User Manual.
To select the driver:
1. Click on the Refresh List button to refresh the list of drivers.
2. Select the driver. To open a list of available drivers, click on the
arrow to the right of the Driver field.
Note: Serial 1 and Serial 2 drivers are provided by the transfer
utility and enable you to configure two different serial setups (for
example, baud rates). Also, they can accommodate the two
communication ports on many computers. Refer to the physical
communication ports on your computer to determine the correct
port for your application.
