General installation information – Rockwell Automation 2711E-ND7 PanelView 1400E File Transfer Utility User Manual
Page 26
2–11
Publication 2711E–6.8 – January 1998
Figure 2.8 Ethernet Pass-Through
ISA Ethernet Card
10 BASET
HUB or
Patch Panel
Ethernet Transceiver
You may install the PanelView 1200/1400e Transfer Utility software
using the CD-ROM provided in the PanelBuilder 1400e software kit
(A-B Catalog Number 2711E-ND1) or disks provided in the
PanelView 1200/1400e Transfer Utility software package (A-B
Catalog Number 2711E-ND7).
You may also obtain floppy disks of the PanelView 1200/1400e
Transfer Utility software by creating them from the PanelBuilder
1400e CD or by sending in the Disk Request Fax Back Form
available in the PanelBuilder 1400e software package (A-B Catalog
Number 2711E-ND1).
For instructions on how to create floppy disks of the software from
the PanelBuilder 1400e CD, refer to the Readme file, titled
Floppies.txt, in the root directory of the PanelBuilder 1400e CD.
General Installation
Information
