A–B
4
Chapter
4–1
Running Applications
This chapter describes screen types and operating procedures that are
common to most applications. It contains the following sections:
Section Page
DIP Switch Setting 4–1
Application Documentation 4–1
Screen Types 4–2
Screen Navigation 4–2
Menu and Sub-Menu Screens 4–3
Security Screens 4–3
Data Display Screens 4–4
Bar Graph Screens 4–4
Data Entry Screens 4–4
ASCII Input 4–5
Recipe Screens 4–6
Alarm Screens 4–6
Before an application can be run, verify that the DIP switch SW-1 is OFF.
This enables the run mode. Refer to the DIP switch description on page 1–5.
It is the responsibility of the application designer to document the operation
of an application program. This chapter only provides basic guidelines.
Before running an application, you should understand what processes are
being controlled and monitored.
Chapter Objectives
DIP Switch Setting
Application
Documentation
