Resetting the dtam plus – Rockwell Automation 2707-L40X_L8X_V40X DTAM Plus Operator Interface Module Installation Instructions User Manual
Page 45
Chapter 3
Using the Function Menu
3–3
Use the Reset function to reset the DTAM Plus after DIP switch changes or a
configuration change using the Function Key Menu.
You can also use the Reset function to activate Terminal Mode if DIP switch
SW-5 is set ON.
To reset the DTAM Plus:
1. From the Function Menu, select Reset [4].
1 C-Port
5 Special
2 P-Port
6 Term
3 Clk/Cal
7 Test
4 Reset
8 Other
This screen appears:
Press ”Y” To Reset
Press ”N” To Abort
2. Press [Y] on the keypad to initiate the reset.
The DTAM Plus resets. This has the same effect as turning the power off
and on. The DTAM Plus performs the self diagnostic tests and powerup
displays as described in the previous section.
Resetting the DTAM Plus
