Special Controller Functions
Appendix C
C–2
To access the Special Functions Menu:
1. Select item 5 from the Function Menu to access the Special Menu:
1 C-Port 5 Special
2 P-Port 6 Term
3 Clk/Cal 7 Test
4 Reset 8 Other
You are prompted:
SLC 50X Network Addr
Press
”Y’ to Edit Address
”N” to Bypass
1. P – A/D
2. R – PORT
Remote I/O
Operating System
PLC-5 DF1
Operating System
DH485
Operating System
DTAMPlus:00 Max:02
SLC Expected At 01
Input NewSLC Node 01
Press ENTER
1. P – A/D
2. SLC 50X Mode
3. Memory Transfer
4. Clear SLC Fault
1. P – A/D
2. PLC Mode
3. Memory Transfer
4. Clear PLC Fault
2. The special functions you can select depends upon the the operating
system.
The Special Menu provides access to one or more of these functions:
1 P-A/D refer to page C–3 for more information.
2 Mode (DH485 or PLC-5 DF1) refer to page C–19 for more information.
2 R Port (Remote I/O) refer to Chapter 3 for more information.
3 Mem Xfer refer to page C–20 for more information.
4 Clr Fault refer to page C–21 for more information.
Accessing Special
Functions
