Remote I/O Versions
The Remote I/O port allows you to connect the DTAM Plus to:
•
a PLC over a Remote I/O link
•
an SLC 1747-SN Scanner
•
a PLC-5 scanner or subscanner
Figure 1.7
Remote I/O Connections
PLC-5
RediPANEL
Remote I/O Network
PanelView
Remote I/O DL40 Plus
Computer
Belden 9463 Cable
(Catalog No. 1770-CD)
DTAM Plus
DTAM Plus to PLC-5 over Remote I/O Link
DTAM Plus
Remote I/O Port
SLC 5/03
Belden 9463 Cable
(Catalog No. 1770-CD)
RIO Scanner
(Catalog No. 1747-SN)
DTAM Plus to SLC Controller
Remote I/O
Communications
