Publication 1769-UM014B-EN-P - May 2010
A-6 Specifications
Table A.3 1769-OF4CI Specifications
Specification 1769-OF4CI
Output Impedance >1 M
Open and Short-circuit
Protection
Yes
Max Short-circuit Current 21 mA
Output Overvoltage Protection Yes
Output Response at System
Power Up and Power Down
No power up or power down current glitch
Rated Working Voltage (1) 30V ac/30V dc
Output Group to Bus Isolation 500V ac or 710V dc for 1 minute (qualification test)
30V ac/30V dc working voltage
Module OK LED On: module has power, has passed internal diagnostics,
and is communicating over the bus.
Off: Any of the above is not true.
Channel Diagnostics Over- or under-range by bit reporting
System Power Supply Distance
Rating
The module may not be more than 8 modules away from
the system power supply.
Recommended Cable Belden 8761 (shielded)
Vendor I.D. Code 1
Product Type Code 10
Product Code 45
Input Words 6
Output Words 5
Configuration Words 32
(1) Rated working voltage is the maximum continuous voltage that can be applied at the input terminal, including the input
signal and the value that floats above ground potential (for example, 10V dc input signal and 20V dc potential above ground).
