Module Diagnostics and Troubleshooting 5-7
1769-IF4I Specific
Configuration
Error
X400
010
0 0000 0000
General configuration error; no additional information
X403
010
0 0000 0011
Invalid real time sample rate value
X404
010
0 0000 0100
Invalid input filter selected (channel 0)
X405
010
0 0000 0101
Invalid input filter selected (channel 1)
X406
010
0 0000 0110
Invalid input filter selected (channel 2)
X407
010
0 0000 0111
Invalid input filter selected (channel 3)
X408
010
0 0000 1000
Invalid input range selected (channel 0)
X409
010
0 0000 1001
Invalid input range selected (channel 1)
X40A
010
0 0000 1010
Invalid input range selected (channel 2)
X40B
010
0 0000 1011
Invalid input range selected (channel 3)
X40C
010
0 0000 1100
Invalid input format selected (channel 0)
X40D
010
0 0000 1101
Invalid input format selected (channel 1)
X40E
010
0 0000 1110
Invalid input format selected (channel 2)
X40F
010
0 0000 1111
Invalid input format selected (channel 3)
X410
010
0 0001 0000
Invalid low alarm data value (channel 0)
X411
010
0 0001 0001
Invalid low alarm data value (channel 1)
X412
010
0 0001 0010
Invalid low alarm data value (channel 2)
X413
010
0 0001 0011
Invalid low alarm data value (channel 3)
X414
010
0 0001 0100
Invalid high alarm data value (channel 0)
X415
010
0 0001 0101
Invalid high alarm data value (channel 1)
X416
010
0 0001 0110
Invalid high alarm data value (channel 2)
X417
010
0 0001 0111
Invalid high alarm data value (channel 3)
X418
010
0 0001 1000
Invalid alarm deadband value (channel 0)
X419
010
0 0001 1001
Invalid alarm deadband value (channel 1)
X41A
010
0 0001 1010
Invalid alarm deadband value (channel 2)
X41B
010
0 0001 1011
Invalid alarm deadband value (channel 3)
X41C
010
0 0001 1100
Alarm not enabled (channel 0)
X41D
010
0 0001 1101
Alarm not enabled (channel 1)
X41E
010
0 0001 1110
Alarm not enabled (channel 2)
X41F
010
0 0001 1111
Alarm not enabled (channel 3)
(1)
X represents the Don’t Care digit.
Table 5.4 1769-IF4I Extended Error Codes
Error Type
Hex
Equivalent
(1)
Module
Error
Code
Extended Error
Information
Code
Error Description
Binary
Binary
