Page 81

Publication 1769-UM014B-EN-P - May 2010
Module Diagnostics and Troubleshooting 5-9
Module Inhibit Function
CompactLogix controllers support the module inhibit function. See your
controller manual for details.
Whenever the output modules are inhibited, the modules enter the program
mode and the output channel is changed to the state configured for the
program mode. Whenever the input modules are inhibited, the modules
continue to provide information about changes at its inputs to the 1769
Compact Bus Master (for example, a CompactLogix controller).
Contacting Rockwell
Automation
If you need to contact Rockwell Automation for assistance, please have the
following information available when you call.
A clear statement of the problem, including a description of what the
system is actually doing. Note the LED state; also note input and output
image words for the module.
List of remedies you have already tried
Controller type and firmware number (See the label on the controller.)
Hardware types in the system, including all I/O modules
Fault code, if the controller is faulted
1769-OF4CI and
-OF4VI Specific
Configuration
Error
X431
010
0 0011 0001
Configuration word 0 illegal bits set (channel 0)
X432
010
0 0011 0010
Configuration word 0 illegal bits set (channel 1)
X433
010
0 0011 0011
Configuration word 0 illegal bits set (channel 2)
X434
010
0 0011 0100
Configuration word 0 illegal bits set (channel 3)
X439
010
0 0011 1001
Configuration word 1 illegal bits set (channel 0)
X43A
010
0 0011 1010
Configuration word 1 illegal bits set (channel 1)
X43B
010
0 0011 1011
Configuration word 1 illegal bits set (channel 2)
X43C
010
0 0011 1100
Configuration word 1 illegal bits set (channel 3)
(1)
X represents the Don’t Care digit.
Table 5.5 1769-OF4CI and -OF4VI Extended Error Codes
Error Type
Hex
Equivalent
(1)
Module
Error
Code
Extended Error
Information
Code
Error Description
Binary
Binary
