Rockwell Automation 1788-CN2FFR EtherNet/IP and ControlNet to FOUNDATION Fieldbus Linking Device User Manual
Page 35

Rockwell Automation Publication 1788-UM057B-EN-P - September 2014
33
Set Up in the Studio 5000 Logix Designer Application
Chapter 2
The color of the text indicates if the online device has the same node address and
tag as the offline configured device.
•
If the text is black, the online and offline node address and tag name
match.
•
If the text is red, the online and offline node address and tag name
do not match.
Add New
Use this function to add field devices when the linking device is not connected to
the field device. The Select Device dialog box displays a list of devices from the
field device catalog. Set the H1 Node Address and Tagname.
Figure 4 - Select Device Dialog Box
