Diagnostics and Troubleshooting Chapter 5
Error Codes
The table below explains the extended error code.
Table 24 - Extended Error Codes
Error Type
Hex
Equivalent
(1)
Module
Error
Code
Extended Error
Information
Code
Error Description
Binary
Binary
No Error
X000
000
0 0000 0000
No Error
General Common
Hardware Error
X200
001
0 0000 0000
General hardware error; no additional information
X201
001
0 0000 0001
Power-up reset state
Hardware-
Specific Error
X300
001
1 0000 0000
General hardware error, loss of external 24V DC power
X301
001
1 0000 0001
Hardware ROM error
X302
001
1 0000 0010
Hardware EEPROM error
X303
001
1 0000 0011
Channel 0 calibration error
X304
001
1 0000 0100
Channel 1 calibration error
X305
001
1 0000 0101
Channel 2 calibration error
X306
001
1 0000 0110
Channel 3 calibration error
X307
001
1 0000 0111
Channel 4 calibration error
X308
001
1 0000 1000
Channel 5 calibration error
X309
001
1 0000 1001
Channel 0 Analog/Digital Converter error
X30A
001
1 0000 1010
Channel 1 Analog/Digital Converter error
X30B
001
1 0000 1011
Channel 2 Analog/Digital Converter error
X30C
001
1 0000 1100
Channel 3 Analog/Digital Converter error
X30D
001
1 0000 1101
Channel 4 Analog/Digital Converter error
X30E
001
1 0000 1110
Channel 5 Analog/Digital Converter error
