Chapter 1 Overview
The table below provide specifications for RTD accuracy and temperature
drift. The ratings apply when a 50/60 Hz filter is used.
Table 2 - RTD Accuracy and Temperature Drift
RTD Type
Maximum Scaled Accuracy
(25 °C with Calibration)
Maximum Scaled Accuracy
(0…60 °C with Calibration)
Maximum Temperature Drift
(from 25 °C without
Calibration)
Copper 426
10
Ω
±0.8 °C (1.44 °F)
±1.1 °C (1.98 °F)
±0.032 °C/°C (0.032 °F/°F)
Nickel 618
120
Ω
±0.3 °C (±0.54 °F)
±0.5
°C (±0.9 °F)
±0.012 °C/
°C (±0.012 °F/°F)
Nickel 672
120
Ω
±0.3 °C (±0.54 °F)
±0.5
°C (±0.9 °F)
±0.012 °C/
°C (±0.012 °F/°F)
Nickel-Iron 518
604
Ω
±0.3 °C (±0.54 °F)
±0.5
°C (±0.9 °F)
±0.015 °C/
°C (±0.015 °F/°F)
Platinum 385
100
Ω
±0.5 °C (±0.9 °F)
±0.9
°C (±1.62 °F)
±0.026 °C/
°C (±0.026 °F/°F)
200
Ω
±0.5 °C (±0.9 °F)
±0.9
°C (±1.62 °F)
±0.026 °C/
°C (±0.026 °F/°F)
500
Ω
±0.5 °C (±0.9 °F)
±0.9
°C (±1.62 °F)
±0.026 °C/
°C (±0.026 °F/°F)
1000
Ω
±0.5 °C (±0.9 °F)
±0.9
°C (±1.62 °F)
±0.026 °C/
°C (±0.026 °F/°F)
Platinum 3916
100
Ω
±0.4 °C (±0.72 °F)
±0.8
°C (±1.44 °F)
±0.023 °C/
°C (±0.023 °F/°F)
200
Ω
±0.4 °C (±0.72 °F)
±0.8
°C (±1.44 °F)
±0.023 °C/
°C (±0.023 °F/°F)
500
Ω
±0.4 °C (±0.72 °F)
±0.8
°C (±1.44 °F)
±0.023 °C/
°C (±0.023 °F/°F)
1000
Ω
±0.4 °C (±0.72 °F)
±0.8
°C (±1.44 °F)
±0.023 °C/
°C (±0.023 °F/°F)
IMPORTANT
When you are using any platinum (385) RTDs with 0.5 mA excitation current, the
module’s accuracy is:
·
±0.5 °C (0.9 °F) after you apply power to the module or perform an
autocalibration at 25 °C (77 °F) ambient, with module operating temperature at
25 °C (77 °F).
·
±[0.5 °C (0.9 °F) + DT ± 0.026 deg./°C (±0.026 deg./°F)] after you apply power
to the module or perform an autocalibration at 25 °C (77 °F) ambient, with
module operating temperature between 0…60 °C (140 °F). DT is the temperature
difference between the actual module operating temperature and 25°C (77 °F).
The value 0.026 deg./°C (±0.026 deg./°F) is the temperature drift shown in the
table above.
·
±0.9 °C after you apply power to the module or perform an autocalibration at
60 °C (140 °F) ambient, with module operating temperature at 60 °C (140 °F).
