Module Data, Status, and Channel Configuration Chapter 4
The table below identifies the number of significant bits used to represent the
input data for each available filter frequency. The number of significant bits is
defined as the number of bits that will have little or no jitter due to noise, and
is used in defining the effective resolution. Note that the resolutions provided
by the filters apply to the raw/proportional data format only.
Table 17 - Input Effective Resolution Versus Input Filter Selection (Across Full Raw/Proportional Range)
Input Type
Number of Significant Bits
10 Hz
50/60 Hz
250 Hz
500 Hz
1000 Hz
100
Ω Platinum 385
Sign + 13 bits
Sign + 11 bits
Sign + 9 bits
Sign + 8 bits
Sign + 6 bits
200
Ω Platinum 385
Sign + 13 bits
Sign + 11 bits
Sign + 9 bits
Sign + 8 bits
Sign + 6 bits
500
Ω Platinum 385 with 0.5 mA excitation current
Sign + 13 bits
Sign + 11 bits
Sign + 9 bits
Sign + 8 bits
Sign + 6 bits
500
Ω Platinum 385 with 1.0 mA excitation current
Sign + 13 bits
Sign + 11 bits
Sign + 9 bits
Sign + 8 bits
Sign + 7 bits
1000
Ω Platinum 385 with 0.5 mA excitation current
Sign + 13 bits
Sign + 11 bits
Sign + 9 bits
Sign + 8 bits
Sign + 6 bits
1000
Ω Platinum 385 with 1.0 mA excitation current
not valid
100
Ω Platinum 3916
Sign + 13 bits
Sign + 11 bits
Sign + 9 bits
Sign + 8 bits
Sign + 6 bits
200
Ω Platinum 3916
Sign + 13 bits
Sign + 11 bits
Sign + 9 bits
Sign + 8 bits
Sign + 6 bits
500
Ω Platinum 3916 with 0.5 mA excitation current
Sign + 13 bits
Sign + 11 bits
Sign + 9 bits
Sign + 8 bits
Sign + 6 bits
500
Ω Platinum 3916 with 1.0 mA excitation current
Sign + 13 bits
Sign + 11 bits
Sign + 9 bits
Sign + 8 bits
Sign + 7 bits
1000
Ω Platinum 3916 with 0.5 mA excitation current Sign + 13 bits Sign + 11 bits Sign + 9 bits
Sign + 8 bits
Sign + 6 bits
1000
Ω Platinum 3916 with 1.0 mA excitation current
not valid
10
Ω Copper 426 with 0.5 mA excitation current
not valid
10
Ω Copper 426 with 1.0 mA excitation current
Sign + 11 bits
Sign + 10 bits
Sign + 9 bits
Sign + 8 bits
Sign + 6 bits
120
Ω Nickel 618
Sign + 13 bits
Sign + 11 bits
Sign + 9 bits
Sign + 8 bits
Sign + 6 bits
120
Ω Nickel 672
Sign + 13 bits
Sign + 11 bits
Sign + 9 bits
Sign + 8 bits
Sign + 6 bits
604
Ω Nickel-Iron 518 with 0.5 mA excitation current Sign + 13 bits Sign + 11 bits Sign + 9 bits
Sign + 8 bits
Sign + 6 bits
604
Ω Nickel-Iron 518 with 1.0 mA excitation current Sign + 13 bits Sign + 11 bits Sign + 9 bits
Sign + 8 bits
Sign + 7 bits
150
Ω with 0.5 mA excitation current
Sign + 13 bits
Sign + 11 bits
Sign + 9 bits
Sign + 8 bits
Sign + 6 bits
150
Ω with 1.0 mA excitation current
Sign + 13 bits
Sign + 11 bits
Sign + 9 bits
Sign + 8 bits
Sign + 6 bits
500
Ω
Sign + 13 bits
Sign + 11 bits
Sign + 9 bits
Sign + 8 bits
Sign + 6 bits
1000
Ω with 0.5 mA excitation current
Sign + 13 bits
Sign + 11 bits
Sign + 9 bits
Sign + 8 bits
Sign + 6 bits
1000
Ω with 1.0 mA excitation current
not valid
3000
Ω with 0.5 mA excitation current
Sign + 13 bits
Sign + 11 bits
Sign + 9 bits
Sign + 8 bits
Sign + 6 bits
3000
Ω with 1.0 mA excitation current
not valid
