B - configuration example, Sample configuration of the analog input module, Configuration example – Rockwell Automation 1771-IL/B , D17716.5.91 ISOLATED ANALOG INPUT Module User Manual
Page 53
Appendix
B
B-1
Configuration Example
The following is a sample configuration for the 1771-IL series B isolated
analog input module. Entering the data shown in Figure B.1 in the
configuration words of the write block transfer data file will result in the
following module setup.
Overall Module Functions Chosen
Digital Filter Time Constant
0.5 seconds
Data Format
2’s Complement Binary
Real Time Sampling Rate
1.5 seconds
Individual Channel Functions Chosen
Input
Range
Scale Value
Low/High (counts)
Channel 1
1-5V
1000/5000
Channel 2
1-5V
-5000/-1000
Channel 3
0-5V
0000/5000
Channel 4
0-5V
-5000/0000
Channel 5
+5V
-2500/2500
Channel 6
+5V
-5000/5000
Channel 7
+10V
-100/100
Channel 8
+10V
-9999/9999
The above configuration for the 1771-IL/B isolated analog input module
would be set up using the following PLC-5 data table file (Figure B.1).
Sample Configuration of the
Analog Input Module
