Rockwell Automation 1771-IL/B , D17716.5.91 ISOLATED ANALOG INPUT Module User Manual
Page 14
Installing the Input Module
Chapter 2
2-3
Figure 2.1
Configuration Jumper Settings for 1771-IL/B Inputs
Channel 1
Channel 2
Channel 3
Channel 4
Channel 5
Channel 6
Channel 7
Channel 8
11847-I
Voltage/Current
Jumper
Edge View
(enlarged)
Side View
Jumper in
Current position.
Jumper in
Voltage position.
Functional Analog Block
