Module Configuration
Chapter 4
4-13
Description
Decimal Bit
(Octal Bit)
Word
Bit 00
Offset Calibration bit. When this bit is set (1), offset calibration is to be
performed. When set, no other calibration function bits can be set. Default is
0, no offset calibration.
37
Bit 01
Gain Calibration bit. When this bit is set (1), gain calibration is to be
performed. When set, no other calibration function bits can be set. Default is
0, no gain calibration.
Word 37
Bit 02
Save calibration values. When this bit is set (1), new calibration values will
be saved in EEPROM. Default = 0, values not saved.
Bits 03-07 Not used.
Bits 08-15
(10-17)
Inhibit Channel Calibration. When this bit is set (1), that particular channel
will not be calibrated. Default = 0, all channels to be calibrated.
In this chapter you learned how to configure your module’s hardware,
condition your inputs and enter your data. Chapter Summary
