Advanced Instruction Set
Chapter 6
6Ć27
Here is an explanation of each value:
Counter Address:
Address of the instruction in the
accumulated value area of data table.
Position:
Current word being operated upon
(accumulated value of counter).
File Length:
Number of words in file (preset value of
the counter).
File A:
Starting address of source file.
File R:
Starting address of destination file.
Word Address: Address of source word or destination
word outside of file.
Rate per Scan:
Number of data words moved per scan.
File to File Move
Symbol: FILE 10
Purpose: Duplicates and transfers your designated file to another file address
that you identified. The original file remains intact.
Syntax: Programmed as an output instruction; requires 5 words of the user
program area.
Function: The counter is incremented internally by the instruction.
WARNING: The counter address for the file-to-file move instruction
should be reserved for that instruction. Do not manipulate the
counter accumulated or preset word. Changes to these values could
result in unpredictable machine operation or a run-time error.
Damage to equipment and/or injury to personnel could occur.
When the rung becomes:
True
The data is transferred from the original file to your designated file.
False
No action is taken.
