Rockwell Automation 1772-LV Mini-PLC - 2/15 Programmable Controller (Series B) Programming and Operations User Manual
Page 171

Quick Reference Section
Appendix A
AĆ2
Table A.A
General Program Information
Instruction Name
Key Symbol
Words of Memory
Required
Examine On
Examine Off
-| |-
-|/|-
1
1
Output Energize
Output Latch
Output Unlatch
-( )-
-(L)-
-(U)-
1
1
1
Branch Start
Branch End
1
1
Timer On-Delay
[1]
Timer Off-Delay
[1]
Retentive Timer On-Delay
[1]
Retentive Timer Reset
[1]
Up Counter
[1]
Down Counter
[1]
Counter Reset
[1]
-(TON)-
-(TOF)-
-(RTO)-
-(RTR)-
-(CTU)-
-(CTD)-
-CTR)-
3
3
3
3
3
3
3
Get
Put
Less than
Equal to
Get Byte
Limit Test
-|G|-
-(PUT)-
-|<|-
-|-=|-
-|B|-
-|L|-
1
1
1
1
1
1
Add
Subtract
Multiply
Divide
-(+)-
-(-)-
-(X)-(X)-
-
(ч)−(ч)
-
1
1
2
2
Master Control Reset
Zone Control Last State
Immediate Input Update
Immediate Output Update
-(MCR)-
-(ZCL)-
-|I|-
-(IOT)-
1
1
1
1
Subroutine Area Instruction
Label
Jump
Jumpt to Subroutine
Return
SBR
-(LBL)-
-(JMP)-
-(JSR)-
-(RET)-
1
1
1
1
1
File-to-File Move
[2]
File-to-Word Move
[2]
Word-to-File Move
[2]
FILE 10
FILE 12
FILE 11
5
4
4
Sequencer Input
[2]
Sequencer Output
[2]
Sequencer Load
[2]
SEQ 1
SEQ 0
SEQ 2
5-8
5-8
5-8
Block Transfer Read
BLOCK
XFER 1
2
Block Transfer Write
BLOCK
XFER 0
2
