10ć8 – Rockwell Automation 1772-LV Mini-PLC - 2/15 Programmable Controller (Series B) Programming and Operations User Manual
Page 130

Block Format Instructions
Chapter 10
10Ć8
Proceed by loading each position of file A with following data:
POSITION 003 0879
POSITION 004 0162
POSITION 005 1982
POSITION 006 9715
POSITION 007 5761
Now file A is loaded.
Press a
HEXADECIMAL DATA MONITOR
FILE TO FILE MOVE
COUNTER ADDR: 200
FILE A: 400-406
POSITION: 001
FILE LENGTH: 007
FILE R: 500-506
POSITION
FILE A DATA
FILE R DATA
001
002
003
004
005
006
007
1257
0721
1257
DATA : 0000
corresponding
input address
11205: using an
Input/Output
Simulator (cat.
no. 1790-DP).
Notice that the
data in file A
transferred to
file R.
0879
0162
1982
9715
5761
0721
0879
0162
1982
9715
5761
KEY
DISPLAY
NOTE: You do not have to enter data in each position. you can skip position
numbers.
Do not clear your controller’s memory. We will use this data to demonstrate
new concepts in section B.
Section B
Editing a File
In this section you will read:
How to edit your file’s data in the hexadecimal data monitor display.
Objectives
