Quick Reference Section
Appendix A
AĆ18
Table A.L
Editing Functions [1]
Function
Key Sequence
Mode
Description
Inserting a condition
instruction
[INSERT]
(Instruction)
(Address)
or
[INSERT] [
←
]
(Instruction)
(Address)
Program
Position the cursor on the instruction that will
precede the instruction to be inserted. Then press
key sequence.
Position the cursor on the instruction that will
follow the instruction to be inserted. The press
key sequence.
Removing a condition
instruction
[REMOVE]
(Instruction)
Program
Position the cursor on the instruction to be
removed and and press the key sequence.
Inserting a rung
[INSERT]
[RUNG]
Program
Position the cursor on any instruction in the
preceding rung and press the key sequence.
Enter instructions and complete the rung.
Removing a rung
[REMOVE]
[RUNG]
Program
Position the cursor anywhere on the rung to be
removed and press the key sequence.
NOTE: Only addresses corresponding to output
energize, latch and unlatch instructions are
cleared to zero.
Change data of a word or
block instruction
[INSERT]
(Data)
Program
Position the cursor on the word or block
instruction whose data is to be changed. Press
the key sequence.
Change the address of a
word or block instruction
[INSERT]
(First Digit)
[
←
]
(Address)
Program
Position the cursor on a word or block instruction
with data and press [INSERT]. Enter the first digit
of the first data value of the instruction. Then use
the [<]and [->] key as needed to cursor up to the
word address. Enter the appropriate digits of the
word address.
On-line programming
[SEARCH]
[5] [2]
Initiates on-line programming.
Replace an instruction or
Change address of an
instruction without data
[Instruction]
(Address)
Program
Position the cursor on the instruction to be
replaced or whose address is to be changed.
Press the desired instruction key (of key
sequence) and the required address(es).
On-Line Data Change
[SEARCH]
[5][1]
(Data)
[RECORD]
[CANCEL
COMMAND]
Run/Program
Position the cursor on the word or block
instruction whose data is to be changed. Press
the key sequence. Cursor keys can be used.
Press [RECORD] to enter the new data into
memory.
To terminate on-line data change.
All editing functions
[CANCEL
COMMAND]
Program
Run/Program
Aborts the operation at the current cursor position.
These functions can also be used during on-line programming.
[1]When bit address exceeds 5 digits, press the [EXPAND ADDR] key before entering address and enter a leading zero if
necessary.
