Chapter 2 Set Up in the Studio 5000 Logix Designer Application
Download
Downloads the configuration to the linking device. The linking device saves the
configuration in non-volatile memory.
Upload
Uploads the configuration from the linking device to the Studio 5000 Logix
Designer project.
Scan
Finds the field devices on the local PA bus and applies a default configuration to
each device according to the GSD file of the manufacturer. The AOP scans up to
the max scan address (see
Max Scan Address on page 31 ).
Add Device
Manually adds a device that is not currently connected. The same default
configuration is applied to the field device that is added.
Copy Device
Copies a field device configuration and applies it to all other locations.
Delete Device
Deletes a device from the tree.
Delete All
Deletes all field devices from the configuration.
IMPORTANT After the configuration has been downloaded to the linking device, cycle
power for the new configuration to take effect.
IMPORTANT Click the Apply button in the AOP to save the configuration to the Studio 5000
Logix Designer project.
TIP If you want to replicate the configuration to many devices, the Copy Device
button can speed up the process.
