35 Rockwell Automation Publication 1608P-UM005A-EN-P - November 2014
Chapter 6 Maintenance
36 COM_VER
Start-Up Test: Communication
Compatibility Mismatch
Call Service Unit
Firmware communication compatibility problem detected during start-up
test.
Call service.
37 CNFG_TO
Start-Up Test: Controller
Configuration Timeout
Call Service Unit Controller communication problem detected during start-up test. Call service.
38 CNFG_ERR
Start-Up Test: Controller
Configuration Mismatch
Call Service Unit Controller firmware configuration problem detected during start-up test. Call service.
39 FIRM_TO
Start-Up Test: Controller Firmware
Check Timeout
Call Service Unit Controller communication problem detected during start-up test. Call service.
40 FIRM_DIFF
Start-Up Test: Controller Firmware
Revision Mismatch
Call Service Unit Controller firmware revision mismatch detected during start-up test. Call service.
41 SRL_TO
Start-Up Test: Controller Serial
Number Check Timeout
Call Service Unit Controller communication problem detected during start-up test. Call service.
42 SRL_DIFF
Start-Up Test: Serial Number
Mismatch
Informational Unit Controller serial number mismatch detected during start-up test. No action needed.
44 T_INV_TO Inverter Test Timeout Call Service Unit Phase control board failed to respond to Comm board's Inverter test. Call service.
47 CRIT_OT Critical Over-Temperature Manual Reset Unit
Internal DySC temperature exceeded maximum rating. Mechanical bypass
commanded.
Verify ambient temperature is within DySC specification.
Check for damaged fans. Check for dirty or obstructed air filters.
Manually reset DySC.
48 FUSE_OPEN Fuse Open Call Service Unit One of the DySC fuses was detected open. Mechanical bypass commanded. Call service.
49 OPEN_SCR_A Open SCR Phase A Call Service Static Switch The SCR on the phase A module was detected open. Call service.
50 OPEN_SCR_B Open SCR Phase B Call Service Static Switch The SCR on the phase B module was detected open. Call service.
51 OPEN_SCR_C Open SCR Phase C Call Service Static Switch The SCR on the phase C module was detected open. Call service.
53 DYN_BRAKE Dynamic Brake Error Call Service Unit A problem was detected with the DySC dynamic brake controller. Call service.
58 PLC_ERR
Programmable Logic Controller
Error
Call Service PLC PLC error detected. Call service.
59 PLC_ST_MM
Programmable Logic Controller
State Mismatch
Call Service Unit PLC feedback error detected. Call service.
73 INPUT_PS_FAIL Input Control Power Supply Failure Call Service Unit System output control power supply is not operating properly. Call service.
74 OUTPUT_PS_FAIL
Output Control Power Supply
Failure
Call Service Unit System output control power supply is not operating properly. Call service.
Event
Code Code Name Full Name Severity Area Event Description Event Resolution
