20 Rockwell Automation Publication 1608P-UM005A-EN-P - November 2014
Chapter 4 Applying Power and Operation
A list of conditions and indications is given in Table 2. Under some conditions
the HC-DySC will automatically close the maintenance bypass switch (CBB)
and open CBI and CBO to prevent damage to the HC-DySC or to protect loads
from severe voltage unbalance. Those conditions are the last four listed in the
table below. Refer to Chapter 5 for further information on system alarms and
status display.
Table 2 - Operational Conditions and Indications
* The touchscreen will power down if both input and output voltages fall below 75% of nominal.
An error message will be displayed while the red or orange text box is displayed. Refer to
Chapter 5 for further information on accessing fault codes and status history.
CONDITION DEFINITION DISPLAY STATUS* INVERTER MODE
Normal: 88.5% < V LINE < 110% Green “OK” Standby Static BP
Sag Event: V LINE < 88.5% for less
than specified runtime
Green “OK” Running Inverter
Runtime Exceeded: Cumulative runtime
exceeded Blinks Red, then Orange for 1
min. Repeats if condition
persists Inhibited Static BP
Normal Mode,
Overload: Load current > 110% Red during OL condition,
Orange for 1 min. after OL ends Inhibited Static BP
Output Over-Current
while inverter running
(I
2 t)
Load current > 150%
for 3 cycles Blinks Red, then Orange for 1
min. Repeats if condition
persists Inhibited Static BP
Inverter Module
Over-temperature: Module temperature
limit exceeded Blue, HC-DySC offline Disconnected Mechanical
Bypass
HC-DySC cabinet
Over-temperature: Internal temperature
limit exceeded Blue, HC-DySC offline Disconnected Mechanical
Bypass
Static Switch Failure: Open SCR(s) Blue, HC-DySC offline Disconnected Mechanical
Bypass
Main Fuse Open Open Fuse(s) Blue, HC-DySC offline Disconnected Mechanical
Bypass
