Rockwell Automation Publication 1512A-UM100F-EN-P - May 2013 39
Chapter
5
Maintenance
Tool Requirements
• Torque wrench: 0...65 N•m (0...48 lb•ft)
• Sockets: 3/8 in., 7/16 in., 9/16 in.
• Ratchet handle and extension
• Wrenches: 7/16 in., 1/2 in., 9/16 in.
• Feeler gauges: 1.3 mm (0.050 in.), 2 mm (0.080 in.), 0.5 mm (0.020 in.)
• Flat-blade screwdriver
• Nyogel 759G Lubricant, Rockwell Automation part no. 80158-357-51
Recommended Torque
Values When reinstalling components, or when reassembling the cabinet, tighten the
following bolt sizes to the specified torque values:
Table 2 - Torque Values for Hardware
ATTENTION: Use suitable personal protective equipment (PPE) per local codes
or regulations. Failure to do so may result in severe burns, injury or death.
IMPORTANT Establish a maintenance and inspection schedule for the equipment. Annual
servicing, or every 20,000 operations (whichever comes sooner) is the
minimum recommended. Extreme operating conditions may warrant
additional attention.
IMPORTANT Some components of this product incorporate Imperial hardware. Rockwell
Automation recommends the use of the appropriate tools to successfully
complete the maintenance procedures on these components. If you cannot
obtain such tools, contact your area Rockwell Automation sales office for
assistance.
1/4 in. hardware 8 N•m (6 lb•ft)
5/16 in. hardware 15 N•m (12 lb•ft)
3/8 in. hardware 27 N•m (20 lb•ft)
1/2 in. hardware 65 N•m (48 lb•ft)
