Figure 30 – Rockwell Automation 1512A MV Controllers, 400A One-High Cabinet, Standard and Arc-Resistant Enclosure User Manual
Page 33
Rockwell Automation Publication 1512A-UM100F-EN-P - May 2013
25
Installation – Arc-Resistant (ArcShield)
Chapter 3
Figure 30 - Removal of Low Voltage Barriers to Access Power Bus
5. Install incoming line cables to power bus. Torque to specifications (refer
Recommended Torque Values on page 2 of Chapter 1
).
6. Reverse procedure after cables have been installed.
Retaining Screws
Bus Access
Barriers
Retaining Screws
