Chapter 5 – Programming
5-31
Table 5.C Motor Operated Potentiometer (MOP) Frequency Source and Accel/Decel Selection
Parameter Settings Frequency Source ➀ Accel/Decel Control Terminal Block
Preset/
2nd Accel (26)
Upper Presets
(72)
Freq
Select 1
(5)
Freq
Select 2
(6)
Accel
Time 1
(7)
Decel
Time 1
(8)
Accel
Time 2
(30)
Decel
Time 2
(31)
SW3
TB2-18
SW2
TB2-17
SW1
TB2-16
Preset
or
Disabled
or
• • • 0 MOP➁ Decrement MOP➂ Increment
or
2nd Accel
or
Enabled
• • • X MOP➁ Decrement MOP➂ Increment
➀ The parameter [Freq Source] indicates the active frequency source. See p. 5-45.
➁ MOP Decrement – When this switch is closed, [MOP Hz] is decreased at the rate programmed in [MOP Increment].
➂ MOP Increment – When this switch is closed, [MOP Hz] is increased at the rate programmed in [MOP Increment].
• Indicates active function/parameter. X Indicates closed switch. 0 Indicates open switch. (26) Indicates parameter number.
